GM 1000 HPS GoTo-Mount

HPS stands for High Precision and Speed and the mount is an advancement of the known GM 2000 QCI of 10Micron with the same proven mechanics, however, less load-carrying capacity than this - and with it highly transportable

The GM 1000 HPS reaches a Satellite tracking and positioning speed from 20 degrees / sek. with an average positioning accuracy <20" and a tracking accuracy of approx. 1"/15min (peak to peak).

The GM 1000 HPS disposes, in addition, of high-precision Absolut-Encoder on both axes which opens absolutely new possibilities. The mount never loses its orientation, even if one axis is shifted by hand. Also after a power failure no new Alignment is necessary. In field use the mount is quicker and easier to install and to align than any conventional equatorial mount.

10micron has modernized the well proven parallactic / equatorial mount. By "Dual Axis Tracking", small errors in the polar axis and other disturbing parameters, such as deflection of the telescope tube, are compensated fully automatically during tracking.

Specifications

Mount Type

German Equatorial Mount

Weight (mount w/o acc.)

~ 19,5 kg – 43 lbs

Instrument Payload Capacity (kg)

25 kg – 55 lbs

Latitude Range

0° – 82° (90° optional)

Azimuth fine adjustment range

+/− 7.5°

Counterweight shaft

30 mm diameter, stainless steel, weight 1.7 kg – 3.7 lbs

Axes

30 mm diameter, alloy steel

Bearings

Pre-loaded tapered roller bearings

Worm wheels

250 teeth, 125 mm diameter, B14 bronze

Worms

20mm diameter, tempered alloy steel, grinded and lapped

Motors

2 axes AC servo brushless

Power supply

24 V DC

Power consumption

~ 0,5 A while tracking ~ 3 A at maximum speed ~ 4 A peak

Go-to speed

Adjustable from 2°/s to 15°/s

Transmission system

Backlash-free system with timing belt and automatic backlash recovery

Pointing accuracy

< 20" with internal 25-stars software mapping - max.100stars; possibility to use the Model Maker software for automated alignment operation.

Average tracking accuracy

~ 1" typical for 15 minutes ~ 0,6" RMS with internal 25-stars software mapping and compensation of system flexures and polar alignment errors

Security stop

+/− 30° past meridian in r.a. (software) +/− 45° past meridian in r.a. (mechanical)

Communication ports

RS–232 port; GPS port; autoguide ST-4 standard port; Ethernet 10/100/1000 port

Database

Stars: by Common Names, Bayer designation, Flamsteed designation, Bright Star Catalogue, SAO, HIP, HD, PPM, ADS, GCVS. Deep-sky: M, NGC, IC, PGC ,UGC limited up to mV = 16. Solar system: Sun, Moon, planets, asteroids, comets, artificial satellites. Equatorial and altazimuth coordinates. User defined objects. Quick slewing positions recalls for frequent focusing or useful operation.

Firmware features

User defined mount parking positions, 2stars and 3stars alignment function, up to 100 alignment stars for modeling, correction of polar alignment and orthogonality errors, estimate of average pointing error, storage of multiple pointing models, sidereal, solar and lunar tracking speed adjustable on both axes, declination-based autoguide speed correction, adjustable horizon height limit, pointing and tracking past meridian, assisted electronic balance adjustment, automatic (ClockSync proprietary software) manual or GPS time & site coordinates synchronization, leap seconds support and full accounting for the UT1-UTC timescale, configurable atmospheric refraction, direct Baader dome control via RS-232, network settings, comets and asteroids filter, multi-language interface. Remote Assist via Internet connection with dedicated server.

Keypad control

Rugged keypad with metal housing and reliable professional micro switches, Large graphic display – heated for operation under lowest temperatures, dimmable display and keyboard with back-lit keys, five information menu lines for coordinates, object information and symbols showing mount status and active external connections and accessories. All the functionality of the mount is available through the keypad without requiring an external PC

PC control

Remote control via RS-232, Ethernet, proprietary 10Micron ASCOM driver, LX200 compatible protocol, update of firmware and orbital elements of comets, asteroids and artificial satellites via RS-232 or Ethernet, PC virtual KeyPad control panel via RS-232 or Ethernet, Integrated Wi-Fi for connection with smartphones and tablets and any wireless network
