Important note:

The Price does not include the counterwights and the power supply unit, these must be ordered in addition (Accessories).
To avoid loss of warranty, only power supplies approved by us from our price list may be used.
Read more: Important Warranty Information regarding astronomical devices
When purchasing a 10Micron mount, the heavy shipping box #1451066 is included.

GM 1000 HPS GoTo-Mount

MORE CAPACITY, SAME CLASS, SAME PRICE:

The GM1000 HPS EP (Enhanced Performance) carries the success story of the GM1000 HPS into the next generation. It is not a replacement but an evolution of the original GM1000 HPS. Through targeted mechanical reinforcements – including a larger 32 mm RA-axis and upgraded bearings – it offers 20 % more payload capacity (30 kg / 66 lbs) while maintaining virtually the same overall weight. This makes it the first choice for astrophotographers who demand maximum stability in a compact mount class.

The GM1000 HPS mount has been, and remains, a benchmark in its segment: a perfect balance of payload capacity, portability, and the legendary pointing and tracking accuracy guaranteed by our HPS technology. HPS stands for High Precision and Speed

The GM1000 HPS is universally recognized for:

Absolute Precision: Thanks to high-precision absolute encoders on both axes, it delivers flawless pointing and tracking, eliminating the need for autoguiding in most applications.
Exceptional Payload-to-Weight Ratio: Optimal payload capacity in a lightweight and easily transportable mount body.
Robustness and Reliability: Built to last and perform night after night, under any conditions.
Advanced Software: A powerful and intuitive control system that offers professional-grade features to all users.
Remote Operation Capabilities & Global Support: Engineered for reliable remote applications, supported by a comprehensive global sales and technical support network.

The GM 1000 HPS EP reaches a go to speed up to 15°/sec, a pointing accuracy <20" and a tracking accuracy of approx. +/- 1" in 15min (0.7" RMS).

In field use the mount is quicker and easier to install and to align than any conventional equatorial mount.

The GM1000 HPS EP is the result of a targeted R&D process aimed at enhancing the mount's key structural and technological areas. Every enhancement must translate into a tangible, measurable benefit for the astrophotographer.

Main innovations – and, more importantly, the advantages:

Increased Payload Capacity – now 30 kg (66 lbs) at the same price:
+ 20% more capacity, e. g. larger-aperture telescopes, heavy filter wheels and cameras – while maintaining maximum stability and tracking accuracy
Reinforced Axis:
Both RA ans DEC axes have been improved with a new design and an increased thickness. The RA diameter has also been increased in diameter. This results in an exponential increase in structural rigidity, drastically reducing vibrations and flexure.
New, Larger and Reinforced Bearings:
As a direct result of the new axis, the larger bearings ensure smoother movements, optimal management of the increased load, and superior longevity of the mechanical system.
Redesigned Worm Gear Supports:
The new mechanical housings have been optimized to integrate more robust and high-performance worm gear supports. This minimizes any potential flexure in the drive system, a critical factor for an excellent tracking.
Enhanced Build Quality and Manufacturing Precision:
The use of new CNC machinery and 3D coordinate measuring machines (CMM) allows tighter mechanical tolerances and consistent quality for every unit.
New V3 control box:
Hardware and Software improvements, leveraging modernized electronics and EU-made industrial-grade connectors for superior performance and robust, long-lasting connections.
Selective Sourcing of Materials:
Stricter material and component selection ensures top-tier performance and dependability.
Enhanced Connectivity & Web Interface:
Unique connectivity options, including a sophisticated web interface, enables comprehensive monitoring and precise adjustments without direct physical interaction.
Optimized for Remote Operation
Global Support Network

Specifications

Mount Type

German Equatorial Mount

Weight (mount w/o acc.)

~ 19,5 kg – 43 lbs

Instrument Payload Capacity (kg)

30 kg – 66 lbs

Latitude Range

0° – 82° (90° optional)

Azimuth fine adjustment range

+/− 7.5°

Counterweight shaft

30 mm diameter, stainless steel, weight 1.7 kg – 3.7 lbs

Axes

32 mm (RA) / 30 mm (DEC) diameter, alloy steel

Bearings

Pre-loaded tapered roller bearings

Worm wheels

250 teeth, 125 mm diameter, B14 bronze

Worm gears diameter

20mm, alloy steel, grinded and lapped

Motors

2 axes AC servo brushless

Power supply

24 V DC

Power consumption

~ 0,5 A while tracking ~ 3 A at maximum speed ~ 4 A peak

Go-to speed

Adjustable from 2°/s to 15°/s

Transmission system

Backlash-free system with timing belt and automatic backlash recovery

Pointing accuracy

< 20" multiple-stars software mapping

Average tracking accuracy

~ 1" typical for 15 minutes ~ 0,7" RMS with multiple-stars software mapping and compensation of flexures and polar alignment errors

Security stop

+/− 30° past meridian in r.a. (software) +/− 45° past meridian in r.a. (mechanical)

Electronic hardware

Built in absolute encoders on both RA & Dec axes, featuring <0.1 arcsec readout error, fully encapsulated and factory calibrated, V3 control box with onboard-intelligence and V3 firmware, standalone system (no PC required). Rugged keypad with metal body and reliable industrial micro switches; large graphic display, with up to five text lines and status icon, heated for low temperature operation, dimmable display and keyboard with LED backlit keys

Communication ports

Ethernet port; RS–232 port; GPS port with PPS signal; Autoguide ST-4 protocol port; AUX port (remote power on/off)

Database

Stars: by name, Bayer designation, Flamsteed designation, Bright Star Catalogue, SAO, HIP, HD, PPM, ADS, GCVS. Deep-sky: M, NGC, IC, PGC, UGC limited up to mV = 16. Solar system: Sun, Moon, planets, asteroids, comets, artificial satellites. Equatorial and altazimuth coordinates; User defined objects

Firmware features

User defined mount parking positions, 2stars and 3stars alignment function, up to 100 alignment stars for modeling, correction of polar alignment and orthogonality errors, estimate of average pointing error, storage of multiple pointing models, sidereal, solar and lunar tracking speed adjustable on both axes, declination-based autoguide speed correction, adjustable horizon height limit, pointing and tracking past meridian, assisted electronic balance adjustment, automatic (ClockSync proprietary software) manual or GPS time & site coordinates synchronization, leap seconds support and full accounting for the UT1-UTC timescale, configurable atmospheric refraction, direct Baader dome control via RS-232, network settings, comets and asteroids filter, multi-language interface. Remote Assist via Internet connection with dedicated server.

PC control

Remote control via RS-232, Ethernet, proprietary 10Micron ASCOM driver, LX200 compatible protocol, update of firmware and orbital elements of comets, asteroids and artificial satellites via RS-232 or Ethernet, PC virtual KeyPad control panel via RS-232 or Ethernet, Integrated Wi-Fi for connection with smartphones and tablets and any wireless network

Web interface

Direct access to the user manuals and command protocols; Download of TLE data as well as comet and asteroid data; Automatic firmware check and easy updates; Virtual hand controller with all the functions of the physical keypad; Compatible with any browser and any device (PCs, laptops, tablets, and smartphones) as well as all operating systems
